SDS150 Series

SDS150 Series
Simple, compact and heavy-duty design - 1 to 12 sections
For open and closed center.
Fitted with a main pressure relief and load checks on each section.
Available with:
Parallel, tandem, or series circuit.
Optional carry-over port.
Port Relief and anticavitation circuit valves.
Ø20mm interchangeable spools.
Manual, electro-hydraulic, hydraulic pilot, pneumatic pilot or cable spool control.
