Product Description:

STAUFF SF series High Pressure Filters are designed for in-line hydraulic applications, with a maximum operating pressure of 420 bar / 6000 PSI. Used together with STAUFF SE series Filter Elements, a high efficiency of contaminant removal is assured. The high dirt-hold capacity of the elements ensures long service life and, as a result, reduced maintenance costs.

Technical Data:

Construction

  • Designed for in-line assembly, with threaded mounting holes on top of the head.

Materials

  • Filter head: Spheroidal Graphite Cast Iron
  • Filter bowl: Cold Drawn Steel
  • O-rings: NBR (Buna-N®), FPM (Viton®), EPDM (Ethylene-Propylene-Diene-Monomer-Rubber)
  • Support ring: PTFE (Polytetrafluoroethylene)

Port Connections

  • BSP
  • NPT
  • SAE O-ring thread
  • SAE Code 61 flange
  • SAE Code 62 flange

   Other port connections available on request.

Operating Pressure

  • 420 bar / 6000 PSI

Burst Pressure

  • 1260 bar / 18275 PSI

Temperature Range

  • -10 °C ... +100 °C / +14 °F ... +212 °F

Filter Elements

  • Specifications see page C22 / C41

Media Compatibility

  • Mineral oils, other fluids on request

Options and Accessories:

Valve

  • Bypass valve: Allows unfiltered oil to bypass the contaminated element once the opening pressure has been reached, a differential  pressure of 6 + 0,5 bar / 87 + 7.25 PSI ∆p is the standard setting. Other settings available upon request.
  • Reverse flow valve: Allows reverse flow through the filter head without backflushing the element.
  • Non-return valve: Prevents draining of the delivery line during element change.
  • Multi-function valve: Opening pressure 6 +0,5 bar / 87 +7.25 PSI
  • Bypass, reverse flow capability and non-return valve combined in one valve.

Clogging Indicator

  • Standard actuating pressure: 5 -0,5 bar / 72.5 -7.25 PSI ∆p

Other actuating pressure settings are available upon request.

  • Available indicators: Visual Electrical

Visual-electrical (24 V DC, 110 V AC, 230 V AC versions)

SF070XXXB-TB/RV 240L PRESS. FILTER-REVERSE FLOW VALVE SF-070-O-O-B-T-G20-R-V 1010000646
